Upper tool turret with X/Y/Z/H-axis with 10 tool holders
Lower tool turret with X/Y/Z/H-axis with 9 tool holders
Rear unit with 8-fold total drive for 3 tools
Hinged belt conveyor
Resy paper belt filter
Traub tool monitoring
FMB LSK 38 loading magazine
Turning diameter 500 mm.
Travel diameter over cross slide Ø 290 mm.
Turning length 1,500 mm.
Speed range 8 - 2,800 rpm with three gear stages.
Spindle bore approx. Ø70 mm
Three-jaw chuck Ø 250 mm, Röhm
Tailstock quill MK4
Quill stroke 180 mm
Protective cover for chuck
Coolant device
Multifix tool holder
Dimensions 3,200 x 1,700 x 1,800 mm
Weight approx. 3,200 kg
Mains voltage 400 V at 50 Hz
Total connected load 24 kVA
Various tool holders
Various drill chucks
Various turning and drilling tools
Interchangeable beacons for three-jaw chuck
Depth stop for main spindle
Tool cabinet
Documentation
